SCHUCH – e8825 Series LED High Bay Fitting for Ex-Zone (Zone 1, 21 / Zone 2, 22)
Technicial Specifications:
Exproof Zone Class: Zone 1, 21 / Zone 2, 22
Exproof Protection (Gas): II 2 G Ex eb mb q IIC T4 Gb
Exproof Protection (Dust): II 2 D Ex tb IIIC T100 °C Db
IP rating: IP66
Rated voltage: 220 - 240 V, 0 Hz, 50/60 Hz
Tₐ: -30 °C to +55 °C
Mounting material: Y-ropes 3301/3302 Y P, Ceiling brackets steel DW 8825 P
Housing Material: Aluminum Casting
ATEX: IBExU 20 ATEX 1117
IECEx : IECEx IBE 20.0028
GET INFORMATION
SCHUCH – e8820 Series LED Exproof Explosion-protected LED floodlight (Zone 1, 21 Zone 2, 22)
Technicial Specifications:
Exproof Zone Class: Zone 1, 21 / Zone 2, 22
Exproof Protection (Gas): II 2 G Ex eb mb q IIC T4 Gb
Exproof Protection (Dust): II 2 D Ex tb IIIC T100 °C Db
IP rating: IP66
Rated voltage: 220 - 240 V, 0 Hz, 50/60 Hz
Tₐ: -30 °C to +55 °C
Housing Material: Die-cast aluminium
ATEX: IBExU 20 ATEX 1117
IECEx : IECEx IBE 20.0028
GET INFORMATION
SCHUCH – Series e865 LED-Light Fitting for Ex-Zone 1/21
Technicial Specifications:
- Exproof Zone Class: Zone 1, 21 / Zone 2, 22
- Exproof Protection (Gases): II 2 G Ex eb mb op is q IIC T4 Gb
- Exproof Protection (Dusts): II 2 D Ex op is tb IIIC T80°C Db
- Protection Degree: IP66
- Power supply: 220-240V AC/DC, 0 or 50/60Hz
- Ambient Temperature: -30 °C to +55 °C
- Body Material: GRP
- ATEX Certificate: IBExU 16 ATEX 1008
- IECEx : IECEx IBE 16.0010
- Emergency Battery (e864 Series) Options Available!
SCHUCH – e855 Series With / Without Battery LED Exproof Exit Luminaire (Zone 1, 21 / Zone 2, 22)
Technical Properties
- Exproof Zone Class: Zone 1, 21 / Zone 2, 22
- Exproof Protection (Gas): II 2 G Ex eb mb op is q IIC T4 Gb
- Exproof Protection (Dust): II 2 D Ex op is tb IIIC T80°C Db
- Sealing Protection: IP66
- Operating Voltage: 220 – 240 V, 0 Hz, 50/60 Hz
- Operating Ambient Temperature: -30 °C to +60 °C
- Body Material: GRP
- ATEX Certificate: IBExU17ATEX1132
- IECEx : IECEx IBE 17.0037
- Emergency Battery (e856 Series) Options Available!
