Materials and Finish
Body: size S; die-cast aluminium (EN AC-44300). Size MS/M/L/XL; extruded aluminium (6060 T6) and end cap in die-cast aluminium (EN AC-44300)
Enclosure: 4mm toughened glass
External screws: A2 with zinc coating treatment
Glass holder: 316L stainless steel with zinc coating treatment
Finish: powder coated white, RAL9016 gloss 30%
Standard corrosion class C5 according to ISO 9223: 2012.
Gearbox GRP: glass fibre reinforced polyester
Bracket: 316L stainless steel
Wire: H07ZZ-F
Gearbox AL: aluminium (EN AC-44300), powder coated.
Installation and Mounting
Luminaire mounting: ceiling or wall with specific brackets (to be ordered separately)
Gear box: pre-wired, 1.5m cable, with bracket included.
Specification
To specify state:
Five luminaire sizes for the best balance between performance and compactness. Robust and lightweight luminiare solution suitable with highest corrosion resistant class (C5). Easy to maintain and install thanks to its remote gear box, intuitive bracket fixation system and quick connector. The most powerful luminaire solution able to replace 600W sodium lamps in entry zone with large choice of optics and advanced lighting technology (CLO, ALO, LumGate…) to suit many tunnel configurations.
As Thorn GTLED Pro
