THORN – IQ WAVE Recessed Modular Luminaires

Our next generation office luminaire features intelligent innovation in 4 key areas, design, optic, control and installation

Design: simple and flowing lines create a modern but simplistic aesthetic perfect for an elegant office interior
Optics: innovative MV tech optic designed by our expert optical team offers excellent uniformity and glare control, direct/indirect light for illuminance on faces and walls to encourage a comfortable, communicative working environment
Controls: Integrated sensors allow you to create flexible control systems suited to your needs. Wireless solution controlled via App with Bluetooth® 4.x – basicDim Wireless. Also available are integrated PIR and microwave sensors.
Installation: with our new red flag design you can easily access the pull up set from below the ceiling without the need to remove the optics from the product, allowing for a more secure fixing to the ceiling

Materials and Finish

Frame and end caps: polycarbonate
Diffuser: polycarbonate, aluminium designed heatsink
Body: highly reflective steel coffer
Gear tray: pre-coated white steel

Installation and Mounting

Suitable for lay in, with accessory suitable for pull up into concealed grid and plasterboard ceilings.

Specification

To specify state:
A lightweight recessed luminaire for exposed T, plasterboard and concealed grid systems with MV tech optic. LED indirect light source. 3000K/4000K colour temperature, CRI>80 and a lifetime of 50 000 hours @ L90 Ta 25°C including high efficiency at 103 Llm/W, UGR<19. With control systems, PIR, MWS, BC.
As Thorn IQ Wave.
