BARTEC – Ex-d Protected Ex-proof Distribution Board

BARTEC – Ex-d Protected Ex-proof Distribution Board

BARTEC
Technical Specifications : Ex-proof Zone Class: hazardous areas – Zone 1 / 21 (Gases) – Zone 2 / 22 (Dusts) Ex-proof Protection (Gases): II 2G Ex d IIC T6..T3 Gb Ex-proof Protection (Dusts): II 2D Ex tb IIIC T85°C..T150°C Db Protection Degree: IP65 / IP66 Power supply (PRC): Conventional ballast 230V – 50Hz (p.f. corrected – cos ρ ≥ 0,95) Ambient Temperature: -20 °C ÷ +40 °C (-55°C ÷ +55°C) Body Material: Glass-Fiber Reinforced Polyester, Steel Sheet, Stainless Steel ATEX Certificate: DEKRA I3ATEXO2O9 OTHER AVAILABLE CERTIFICATES : IECEx, CU TR GET INFORMATION
Get a Quote

Categories: Ex-proof Distribution Board, Ex-proof Panel, Ex-proof Products

Share:

[vc_row][vc_column][vc_column_text woodmart_inline=”no” text_larger=”no”]Dimensions:

  • Type 1: 380 mm x 300 mm, 1 Hinged Control Window
  • Type 2: 760 mm x 300 mm, 2 Hinged Control Window
  • Type 3: 760 mm x 600 mm, 3/4 Hinged Control Window



Common Applications:

Power supply / distribution for lighting, heating, motors, sockets[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column width=”1/2″]

TECHNICAL DOCUMENT

BARTEC - Flameproof enclosures EJC Ex d IIC, Aluminium - DATASHEET
[/vc_column][vc_column width=”1/2″]

CERTIFICATES

BARTEC - Flameproof enclosures EJC Ex d IIC, Aluminium - Certificates
[/vc_column][/vc_row]
