ARTIDOR – ZONE 1 EVAPORATOR – AR-050
-
Technical Specifications
-
Nominal Capacity: 2 to 14 kW
-
Explosion Protection: II 2 G Ex db eb h ia IIC T4 Gb
-
Compliance: European Directive 2014/34/EU (ATEX 114)
-
Applied Standards:
-
EN 60079-0:2012 / A11:2013
-
EN 60079-1:2014
-
EN 60079-7:2015 / A1:2018
-
EN 60079-11:2012
-
EN 80079-36:2016
-
EN 80079-37:2016
-
-
Certification: EU Type Examination Certificate No. KIWA 19ATEX0049X
-
Ambient Temperature Range: -20 °C to +55 °C
-
Power Supply: 220 – 240 VAC, 50 Hz (Optional: 400 VAC, 3-phase, 50 Hz)
-
Fin Spacing: 4 or 6 mm
-
Refrigerant: R513A
-
Artidor Zone 1 Evaporator AR-050: Industrial Explosion-Proof Cooling Solution
The Artidor Zone 1 Evaporator AR-050 is an ATEX-certified air handling and evaporator unit designed to provide safe temperature control in hazardous environments. It is an ideal solution for chemical storage facilities, flammable material warehouses, and industrial battery charging stations.
MAIN FEATURES
Explosion-Proof Design
-
Flameproof electric motor
-
Antistatic aluminum fan blades
-
Intrinsically safe control circuits
High-Efficiency Cooling
-
Finned copper tube heat exchangers
-
Aluminum fin design
-
Compatible with R513A refrigerant
TECHNICAL ADVANTAGES
-
Compact Design: Easy installation in confined spaces
-
Energy Efficiency: Reduced power consumption for cost savings
-
Flexible Configuration: Optional Zone 2 compliant version
APPLICATION AREAS
-
Chemical and petrochemical plants
-
Industrial battery charging rooms
-
Production facilities with flammable gases
CERTIFICATIONS & STANDARDS
-
Complies with ATEX 2014/34/EU (II 2G IIC T4)
-
CE marked
-
IP54 protection class
ADDITIONAL SERVICES
-
Project-based customized solutions
-
Technical consultancy and installation support
-
Spare parts and maintenance services
WHY CHOOSE THE ARTIDOR ZONE 1 EVAPORATOR AR-050?
-
100% European manufacturing quality
-
Long service life and robust design
-
Wide service network
Teknik Özellikler Tablosu
| Özellik | Değer |
|---|---|
| Cooling Capacity | 5 kW |
| Operating Temperature | -20°C ~ +40°C |
| Air Flow Rate | 1200 m³/h |
| Weight | 28 kg |
The Artidor Zone 1 Evaporator AR-050 is the ideal choice for safe and efficient cooling in hazardous environments, ensuring reliable operation and compliance with international standards.
The Artidor Zone 1 Evaporator AR-050 is a reliable and efficient solution for your industrial cooling needs. For more information, please contact us.
