THORN – NOVALINE STYLE Wall Mounted Luminaires

Innovative LED luminaire with sound absorbing features to minimise sound reverberation in classrooms

Fully compliant with BB93 (measured for an empty classroom) for optimum classroom performance
Achieves the acoustic and lighting standards with only 6 fittings in 56m² classrooms
Wide range of control options, including simple ON/OFF, dimming and sensor
Designed for flexibility offering a choice of infills to adapt the length of the system to match all classroom layouts

Materials and Finish

Raft: aluminium
Luminaire frame: aluminium, powder coated white as standard (RAL9010)
Acoustic material: rocksilk mineral wool fibre
Optic: acrylic

Installation and Mounting

Suitable for suspension mounting with 4 suspension wires (supplied). Suspension wires are adjustable in height due to the support on the luminaire with millimetre movements, in 2 directions. This product can be used in a system with added infill panels to fulfil the acoustic requirement. Through wiring and quick connector are also provided to aid a fast installation. Sensor version also available with Master and Slave control.

Specification

To specify state:
Innovative acoustic LED luminaire to comply with the BB93 norms and EN12464 inside an empty classroom. Wide variety of infills and accessories to maximise the flexibility.
As Thorn Arena Symphony LED.
